What is a Collapsing Toolbar?

A Collapsing Toolbar is a part of the Android Material Design UI components. It provides a way to implement a dynamically expanding or collapsing toolbar at the top of the screen. This toolbar can contain images, text, and other widgets, and it reacts to scrolling events in a coordinating layout.

Why Use a Collapsing Toolbar?

1. Aesthetic Appeal: Enhances the visual appeal of an app, especially when combined with images or graphics.
2. Space Efficiency: Maximizes the space for content by hiding less important elements during scrolling.
3. Improved UX: Offers a dynamic and interactive user experience.

Where to Use a Collapsing Toolbar?

Collapsing Toolbars are typically used in:

• Detail screens where large images are prominent (like in a travel app showing location details).
• Profiles or content screens where focus shifts from the image/header to the content.

To integrate a Collapsing Toolbar in an Android application, you’ll follow several key steps. Below, I provide a step-by-step guide along with code explanations. Additionally, I’ve already provided an illustrative image of what a Collapsing Toolbar looks like in an Android app.

Step 1: Add Dependencies

First, you need to ensure that your project includes the Material Design library.

• Edit your build.gradle (Module: app) file:

dependencies {
     implementation 'com.google.android.material:material:<latest_version>'
     implementation 'androidx.appcompat:appcompat:<latest_version>'
     implementation 'androidx.coordinatorlayout:coordinatorlayout:<latest_version>'
}

Step 2: XML Layout

Create your layout with CoordinatorLayout as the root. Inside it, place an AppBarLayout, then the CollapsingToolbarLayout, and finally, a Toolbar.

• Example XML layout:

<androidx.coordinatorlayout.widget.CoordinatorLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".YourActivity">

    <com.google.android.material.appbar.AppBarLayout
        android:layout_height="wrap_content"
        android:layout_width="match_parent">

        <com.google.android.material.appbar.CollapsingToolbarLayout
            android:id="@+id/collapsing_toolbar"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            app:layout_scrollFlags="scroll|exitUntilCollapsed">

            <ImageView
                android:layout_width="match_parent"
                android:layout_height="200dp"
                android:scaleType="centerCrop"
                app:layout_collapseMode="parallax"
                android:src="@drawable/your_image" />

            <androidx.appcompat.widget.Toolbar
                android:id="@+id/toolbar"
                android:layout_width="match_parent"
                android:layout_height="?attr/actionBarSize"
                app:layout_collapseMode="pin" />

        </com.google.android.material.appbar.CollapsingToolbarLayout>

    </com.google.android.material.appbar.AppBarLayout>

    <!-- Your scrolling content here -->

</androidx.coordinatorlayout.widget.CoordinatorLayout>

• CoordinatorLayout: A super-powered FrameLayout to coordinate the motion and transformation of its children.
• AppBarLayout: Works as a wrapper for the toolbar, providing elevation and scroll behaviors.
• CollapsingToolbarLayout: Allows the toolbar to expand and collapse.
• Toolbar: Acts as the actual toolbar within the collapsing layout.

Step 3: Setup in Activity

Configure the Toolbar in your Activity:

• Example in Java:

import androidx.appcompat.app.AppCompatActivity
import android.os.Bundle
import androidx.appcompat.widget.Toolbar
import com.google.android.material.appbar.CollapsingToolbarLayout

class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

        val toolbar: Toolbar = findViewById(R.id.toolbar)
        setSupportActionBar(toolbar)

        val collapsingToolbar: CollapsingToolbarLayout = findViewById(R.id.collapsingToolbar)
        collapsingToolbar.title = "Your Title"
    }
}

• setSupportActionBar(): Sets the toolbar as the app bar for the activity.
• setTitle(): Sets the title for the CollapsingToolbarLayout.

Step 4: Customize Behavior and Appearance

Customize the behavior and appearance of the Collapsing Toolbar in the XML layout or programmatically in your Java/Kotlin code.

• app:layout_scrollFlags: Defines the scroll behavior of the toolbar. "scroll|exitUntilCollapsed" makes it stay visible until it's fully scrolled off.
• app:layout_collapseMode: Defines how the child views of the CollapsingToolbarLayout will react when scrolling. "parallax" for background images and "pin" for the toolbar.

Step 5: Run and Test

Finally, run your application and test the collapsing behavior by scrolling your content.

This approach sets up a basic Collapsing Toolbar. You can enhance it further by adding more components, customising animations, and fine-tuning the layout to suit your app’s design needs.
